Full Height Turnstiles

Name: Full Height Turnstiles
Brand: HI TECH DOORS
Price: 25000 INR
Availability: InStock

Get a Price/Quote

MOQ : 1 , , Piece

Full Height Turnstiles Specification

Product Type
Full Height Turnstiles

Power Supply
AC 220V 10%, 50Hz

Voltage
DC 24V (motor drive and control)

Application
Industrial, Commercial, Institutional Entrances, Security Checkpoints

Usage
Access Control, Security Management

Camera
Optional Integration Available

Function
Bi-directional Movement, Anti-tailgating

Dimension (L*W*H)
1500mm x 1500mm x 2200mm

Color
Stainless Steel Finish (Custom Colors Available)

Weight
Approx. 120kg

Communication Interface
RS485, Dry Contact

Passage Width
600mm (standard)

Noise Level
60 dB

Operating Mode
Single or Double Lane Available

Unlock Time
0.2 seconds

Material
Heavy-duty SUS304 Stainless Steel

IP Rating
IP54

Relative Humidity
90% RH (non-condensing)

Operating Temperature
-25C to +70C

Power Consumption
Max. 70W

Emergency Mode
Automatic Free Passage in Emergency

Pass Rate
20-30 persons/minute (RFID) / 15-25 persons/minute (Fingerprint)

Control System
Compatible with RFID, Biometric, Barcode readers

Surface Treatment
Brushed / Polished

Full Height Turnstiles Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
1 , , Piece Per Day

Delivery Time
7-10 Days

About Full Height Turnstiles

Full Height Turnstiles comes in the form of a gate which allows only a single person to pass at a time. It is widely used in different application like defense establishments, banks, office buildings and dock yards for security purposes. Further, our offered turnstiles are thoroughly checked by our quality controllers on different quality parameters in order to deliver defect range to our valued customers. These Full Height Turnstiles are known for their unique features like based on highly advanced mechanism, longer service life, high efficiency and excellent throughput.

Enhanced Security Management

These full height turnstiles provide superior protection at entry points, leveraging anti-tailgating technology and bi-directional operation to prevent unauthorized access. Their heavy-duty stainless steel build and double lane option support high-security environments such as industrial complexes, institutional buildings, and secure commercial zones.

Reliable Operation in Varied Conditions

Designed to function seamlessly between -25C and +70C and up to 90% relative humidity, these turnstiles ensure dependable performance regardless of external weather or indoor environmental changes. The IP54 rating and robust construction further guarantee long-term reliability and low maintenance.

Flexible Integration and Customization

With compatibility for RFID, biometric, and barcode access control systems, and availability of optional camera integration, these turnstiles can be tailored to meet various security protocols. Custom colors and surface treatments (brushed or polished) allow the turnstiles to match aesthetic preferences or corporate branding.

FAQs of Full Height Turnstiles:

Q: How is the full height turnstile installed and where can it be used?

A: The turnstile is typically installed at entry and exit points of industrial, commercial, institutional, and security checkpoints. Its heavy-duty SUS304 stainless steel construction, robust IP54 rating, and adaptability to various environments make it suitable for both indoor and outdoor usage across different sectors.

Q: What access control systems are compatible with these turnstiles?

A: These turnstiles are fully compatible with RFID card readers, biometric systems (such as fingerprint scanners), and barcode readers. Integration is supported via RS485 and dry contact communication interfaces, allowing flexible connectivity with most popular security management systems.

Q: When does the emergency mode activate, and what happens during emergencies?

A: In emergency situations, such as fire alarms or power failures, the turnstiles automatic free passage function is triggered. This ensures unobstructed, safe evacuation by allowing passage without requiring authentication, prioritizing safety and compliance with emergency protocols.

Q: What is the typical pass rate and unlock time for this turnstile?

A: Under RFID authentication, the turnstile permits 20 to 30 persons per minute, while fingerprint systems allow 15 to 25 persons per minute. It unlocks within 0.2 seconds, enabling swift and smooth transit, even during peak entry periods.

Q: How does the anti-tailgating feature benefit security management?

A: The anti-tailgating technology detects and prevents multiple people from following a single authorized entrant, significantly reducing the risk of unauthorized access and enhancing overall site security.

Q: Can the turnstiles appearance be customized to match facility aesthetics?

A: Yes, the turnstile offers brushed or polished surface treatments and is available in the standard stainless steel finish with optional custom colors. This allows you to harmonize the turnstile with your facilitys design or branding requirements.
