High Speed Doors

Name: High Speed Doors
Brand: HI TECH DOORS
Price: 250000 INR
Availability: InStock

Price 250000 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

High Speed Doors Specification

Cable Length
3 meters standard

Speed Range
Up to 2.0 m/s

Processor Type
PLC

Connectivity Type
Wired

Remote Control
Yes

Frequency
50 Hz / 60 Hz

Control Type
Microprocessor-based control panel

Screen Size
7 inch (Control Panel Display if applicable)

IP Rating
IP54

Load Capacity
Suitable for high volume operation

Sensor Type
Photoelectric Sensors

Automation Grade
Automatic

Features
Self-repairing, wind resistant, high cycle life, safety edge

Application
Warehouses, Cold Storage, Loading Bays, Manufacturing Units

Phase
Single Phase / Three Phase

Drive Type
Direct Drive

Weight
Depends on door size (approx. 120-250 kg)

Mounting Type
Wall Mounted

Material
High-grade PVC fabric with galvanized steel frame

Power
0.75 kW to 2.2 kW

Temperature
-30C to +70C

Voltage
220V / 380V

Opening Mechanism
Push Button/Remote/Radar Sensor/Induction Loop

Closing Speed
0.5-1.0 m/s

Emergency Opening
Manual Override with Hand Crank

Sound Level
< 70 dB

Door Color Options
Blue, Yellow, Grey, Red (customizable)

Door Curtain Thickness
1.0 mm to 1.2 mm

Maximum Door Size
W 6000 mm × H 6000 mm

Opening Direction
Vertical

Safety System
Infrared Safety Beam, Soft Bottom Edge

Wind Resistance
Up to 90 km/h

High Speed Doors Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
1 , , Piece Per Day

Delivery Time
7-10 Days

About High Speed Doors

High Speed Doors are manufactured under the stern guidance of our deft professionals by using latest technologies keeping in mind the set quality norms. These door can be used for inside and outside in sheltered areas. It is widely used in commercial sectors due to their unique features like sturdy design, noiseless and smoother movement. Apart from this, our offered door can be closed as well as opened easily with fast speed and available in customized sizes and other specifications. These High Speed Doors are checked by our qualities experts on various quality parameters in order to supply defect free range to our valued customers.

Advanced Safety Systems

Safety is paramount with our High Speed Doors. Each door is equipped with an infrared safety beam and a soft bottom edge, designed to minimize risks during operation. The emergency manual override with a hand crank ensures that the door can be operated safely in power outage situations. A microprocessor-based control panel provides reliable monitoring and quick troubleshooting.

Versatile Operation and Customization

These doors support multiple opening mechanisms, including push button, remote, radar sensor, and induction loop, providing flexibility to meet diverse workflow requirements. Available in blue, yellow, grey, and red, with further customization possible, the doors can seamlessly blend with your facilitys identity. Their wall-mounted design, PLC control, and 7-inch display enhance user experience.

Efficient Performance in Extreme Conditions

With a temperature resilience from -30C to +70C, IP54 rating, and wind resistance up to 90 km/h, these doors are suitable for both indoor and outdoor applications. High cycle life and direct drive ensure dependable performance even with frequent high-volume use, making them ideal for fast-paced industrial settings.

FAQs of High Speed Doors:

Q: How are the High Speed Doors operated and what activation options are available?

A: The doors can be operated using a push button, remote control, radar sensor, or induction loop. This flexibility allows users to choose the method that best fits their operational workflow, ensuring convenient and hands-free access where needed.

Q: What safety features are included with the High Speed Doors?

A: Each door includes an infrared safety beam and a soft safety edge to detect obstructions and prevent injury or damage during closing. In case of electrical failure, a manual override with a hand crank ensures the door can always be opened safely.

Q: When should I consider using High Speed Doors with these specifications?

A: These doors are ideal for areas requiring rapid access, reliable insulation, and high-frequency use, such as warehouses, cold storage, manufacturing units, and loading bays. Their design ensures minimal downtime and maintains efficient traffic flow in busy environments.

Q: Where can the High Speed Doors be installed, and what are the mounting options?

A: The doors are suitable for industrial settings and are wall-mounted for stable, secure installation. They can be fitted in both exterior and interior locations, provided the installation site meets the space and power requirements.

Q: What is the process for customizing the door color and size?

A: You can choose from standard colors like blue, yellow, grey, or red, or request a custom color to match your facilitys branding. Sizes up to 6000 mm by 6000 mm are available, and customization requests can be specified during the order process.

Q: What are the benefits of the self-repairing and wind-resistant features?

A: Self-repairing functionality allows the door curtain to reset itself after accidental impacts, reducing maintenance downtime. High wind resistance (up to 90 km/h) ensures consistent operation and minimizes damage during adverse weather conditions.
