Industrial Sectional Doors

Name: Industrial Sectional Doors
Brand: HI TECH DOORS
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Industrial Sectional Doors Specification

Load Capacity
Up to 450 kg (door leaf weight, varies with size)

Sensor Type
Photo sensors/Safety edge sensors

Phase
Single phase / Three phase

Remote Control
Yes

Automation Grade
Automatic / Semi-automatic

IP Rating
IP54/IP65

Frequency
50/60 Hz

Cable Length
Standard 3-5 meters; customizable

Control Type
Push button/Remote

Features
Energy efficient, corrosion resistant, low maintenance, sound insulation, thermal insulation

Mounting Type
Wall/Ceiling Mounted

Speed Range
Up to 0.25-0.30 m/s

Application
Warehouses, Industrial units, Commercial buildings, Loading bays

Connectivity Type
Wired/Optional Wireless

Weight
Varies as per door size & material

Drive Type
Direct/Shaft drive motor

Material
Galvanized Steel / Insulated Steel Panels

Power
Electric operated, power as per motor specification (commonly 0.75 HP to 2 HP)

Temperature
-20C to +60C operating range

Voltage
230-415 V AC

Panel Type
Double skin steel panels, insulated with PU foam

Customization
Available in customized sizes and finishes

Wind Resistance
Tested up to wind load class 4 (as per EN 12424)

Safety Devices
Anti-drop safety device, spring break device

Finish Type
Powder coated/RAL color finish

Operation Mode
Manual override provided

Sealing Type
Rubber sealing at periphery to prevent dust & rain ingress

Opening Style
Vertical lift sectional

Panel Thickness
40 mm to 50 mm

Noise Level
< 60 dB(A)

Industrial Sectional Doors Trade Information

Minimum Order Quantity
1 Piece

FOB Port
KANPUR NAGAR

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
1 Piece Per Day

Delivery Time
7-10 Days

Main Domestic Market
Uttar Pradesh

Industrial Sectional Doors About

Industrial Sectional Doors are available in various industries due their easy installation, rigid structure and fine finish, which can withstand adverse weather conditions. These doors are open vertically and thus create more space in front of and behind the door. Further, our offered door is available in different specifications and can be customized as per the requirements of our valued customers. Our offered Industrial Sectional Doors are made under the guidance of our expert supervisors by using best quality steel and sophisticated technologies keeping in mind the set industrial norms.

Superior Durability & Customization

Industrial sectional doors are built from galvanized steel with advanced powder-coated or RAL finishes and are available in multiple customized sizes and finishes to fit any industrial application. Their robust double-skin PU foam-insulated panels provide exceptional strength, corrosion resistance, and long-lasting performance.

Enhanced Safety and Security

Equipped with anti-drop and spring break safety devices, these doors offer reassuring protection against operational hazards. Comprehensive sealing around the periphery prevents dust and rain ingress, while noise remains lower than 60 dB(A), ensuring a secure and quiet working environment.

Efficient Operation & Energy Savings

Featuring electric or manual override operations, direct or shaft-drive motors, and remote or push-button controls, these doors can be tailored for automatic or semi-automatic usage. The high insulation and quality sealing contribute to significant energy efficiency, helping manage indoor temperatures and reducing energy costs.

FAQ's of Industrial Sectional Doors:

Q: How does the vertical lift sectional door operate in industrial environments?

A: The vertical lift sectional door opens upwards by sliding along the wall, making it ideal for maximizing space in warehouses or loading bays. Its direct or shaft drive electric motor ensures smooth and reliable operation, with a manual override available for emergencies.

Q: What is the benefit of double-skin, PU foam-insulated panels in these doors?

A: Double-skin, PU foam-insulated panels provide both thermal and sound insulation, significantly reducing heat loss and noise transfer. This construction ensures energy efficiency and a comfortable indoor environment, even in extreme temperature conditions.

Q: When is it recommended to opt for a higher wind resistance class in industrial doors?

A: Choosing a door tested to wind load class 4 (EN 12424) is recommended for facilities located in high-wind areas or exposed locations. This ensures the sectional door remains structurally sound and operational under severe weather conditions.

Q: Where can these industrial sectional doors be installed for optimal utility?

A: These doors are suitable for warehouses, industrial units, commercial buildings, and loading bays. Their rugged construction and flexibility in mounting (wall or ceiling) ensure they adapt seamlessly to various industrial settings across India.

Q: What safety features are included to prevent accidents during door operation?

A: Key safety features include an anti-drop safety device and a spring break device, which protect against accidental door falls or spring failures. Sensors such as photo sensors or safety edge sensors detect obstructions, automatically stopping the door to ensure user safety.

Q: How does the sealing system protect the facility against external elements?

A: A robust rubber seal runs around the door's periphery, effectively blocking dust, rain, and drafts from entering the facility. This not only helps maintain optimal environmental conditions inside but also extends the lifespan of stored goods and machinery.
